SWMJ Hand Type Colding Welding Machine

Welding results is perfect.
Pulling force test: constant to the joints.
The resistance test: Resistance value is not greater than that of the original wire.
Changes of wire diameter: In order to meet the user’s need for welding the wires of various materials our company can provide the cold welding dies having various kind if inner grooves for users
Without power supply, safe and reliable, simple operation and welding, after welding the resistance of the material material elongation and related physical and chemical indicators won’t change.

Parameters

How to choose the model

Item	Model	Copper wire size	Aluminum wire size	Dimension	N.W	Die
Item	Model	(mm)	(mm)	(mm)	N.W	Die
J1 Portable	SWM-J1	Φ0.10~0.50	Φ0.10~0.50	160x50x160	1Kg	J1
J1	SWJ1T	Φ0.10~0.55	Φ0.10~0.60	260×90×220	3Kg	J1
J2	SWM-2T	Φ0.30-Φ1.20	Φ0.30-Φ1.40	220x130x200	9.5Kg	J2
J3	SWM-3T	Φ1.00-Φ3.25	Φ1.00-Φ5.00	300x180x300	36Kg	J3
J4TY	SWM- J4TY	Φ1.00-Φ4.00	Φ1.00-Φ6.00	550x550x920	130Kg	J4
J5TY	SWM-J5TY	Φ4.00-Φ8.00	Φ4.00- 14.00	1190x570x1100	650Kg	J4

Specification

Product use	Copper, aluminum, gold, silver, nickel, platinum, zinc, tin, tantalum, niobium and other non-ferrous metals and their alloy wires’ cold welding.
Welding Size	Cu:Φ0.10~0.50mm, Al: Φ0.10~0.50mm,
Body material	Casting stainless steel
Advantage	Without power supply, safe and reliable, simple operation and welding, after welding the resistance of the material elongation and related physical and chemical indicators won’t change.
Dimensions	L×W×H 190mm×50mm×60 mm
G.W	1.0Kg
Dies	J1
